  • ELING TR Tachometer 8000RPM 10000RPM Classical
  • ELING TR Tachometer 8000RPM 10000RPM Classical
  • ELING TR Tachometer 8000RPM 10000RPM Classical
  • ELING TR Tachometer 8000RPM 10000RPM Classical
ELING TR Tachometer 8000RPM 10000RPM Classical ELING TR Tachometer 8000RPM 10000RPM Classical ELING TR Tachometer 8000RPM 10000RPM Classical ELING TR Tachometer 8000RPM 10000RPM Classical

ELING TR Tachometer 8000RPM 10000RPM Classical

  • Product Item:TR Tachometer 8000RPM 10000RPM Classical
  • Fixing dimension: 85mm(3-3/8")
  • Indicating Range: 0-8000RPM,0-10000RPM
  • Speed Ratio: 0.5-327 adjustable
  • Backlight: Red and Yellow
  • Tachometer  , RPM Gauge Meter  , REV Counter
    Inquiry Send Email PDF

    Description

    Key Features:


    -Be suitable for all kinds of tacho sensors, and display the rotation speed of the engine.


    -Use moving-magnet principle to drive the needle, featuring good endurance and anti-vibration.


    -IP67 waterproof and dustproof grade


    -Stepper motors used for full range of stepping gauges, great feature with its less power consumption, longer life, higher precision, etc.


    -With curved glass (with anti-fogging function)


    -With ultra-wide working voltage design( long-term operating voltage: 8-80VDC.


    Technical Data:


    -Fixing dimension: 85mm(3-3/8")


    -Indicating Range: 0-8000RPM,0-10000RPM


    -Speed Ratio: 0.5-327 adjustable


    -Suitable for gasoline engine


    -There is a button in the back of tachometer, you can press it to adjust speed ratio, hour and BUZZ.


    When engine is in idle state, tachometer shows 600-800RPM, it means speed ratio is correct.


    If not, you can turn down or up speed ratio to see the difference of tachometer needle.


    -Working Voltage: 8-80V(12V/24V)


    -Backlight: Red and Yellow


    -Operation mode: LCD display, stepper motor


    -Functions: current tacho/RPM and hour, hourmeter can be reset.


    Package Includes:


    1x Tachometer


    1x Multi-plug socket


    1x External Button


    1x Installation Instruction
